ALTAI IX500 - Wall Mount (Concrete) Installation

6
Altai Technologies Ltd. All rights reserved
Quick Setup Guide
Option 2: Wall Mount (Concrete Wall)
1
Determine where the AP is to be placed and mark location on the
wall surface for the two mounting holes of the mount base. Use an
appropriate drill bit to drill holes of 1/3” (8.1mm) diameter and 1”
(26mm) deep. Screw the anchors into the holes and then insert the
screws through the mount base to the anchors to attach the base to
the wall.
2
Slide the base into the
slot of the AP.
