Quick Setup Guide
Mounting Options
Option 1: T-Rail Ceiling Mount (9/16” T-Rail OR 15/16” T-Rail)
2
Insert an appropriately sized ceiling rail
into one of the mount base slots first. Then
turn the AP slightly so that the rail slips into
another slot to lock the AP into place.
1
Select an appropriate ceiling
mount base (9/16” or 15/16”)
and slide the base into the
slot of the AP.
