Altair MAP1216 - REAR PANEL. MAP128 and MAP1216 Models Shown

5
2.2 REAR PANEL. MAP128 and MAP1216 models shown
MAINS connector.
FUSE holder.
IEC type
ETHERNET connection
RJ-45
LINK CONNECTIONS
RJ-45 / RJ-45
REMOTES
RJ-11 6/4
GENERAL PURPOSE
INPUTS OUTPUTS
Logic connections
Phoenix ® (3.5mm)
BALANCED ANALOG
AUDIO INPUTS/OUTPUTS
Phoenix ® (3.5mm)
