Altec Lansing ACS48 - System Specifications and Warranty; Technical Specifications

Specifications
ACS48
Drivers (satellites) One 3 inch mid-range
One
3
/4 inch tweeter
Drivers (subwoofer) One 6 inch long throw woofer
Frequency Response 32Hz – 20kHz
Satellite Power 20 Watts RMS per channel
at <0.8% THD
Subwoofer Power 40 Watts at <0.8% THD
Input Impedance >10k Ohms
Signal-to-Noise Ratio >80dB
Crossover Frequency
(Subwoofer) 150Hz
Crossover Frequency
(Satellites) 4kHz
Fuse Type* 2 AMP 250V
“Slow Blow” (5x20mm size)
*Before replacing fuse remove AC power plug from the wall
outlet. To replace fuse, twist fuse cap counterclockwise with
a standard flat head screwdriver. The fuse cap is spring
loaded and will “pop” out.
NOTE: IF THE FUSE NEEDS REPLACEMENT USE A 250 VOLT,
2 AMP “SLOW BLOW” 5 X 20MM UL/CSA APPROVED TYPE.
7
Power Requirements
USA/CANADA Model 120 Volts 60Hz AC
MAX Power Consumption 175 Watts
UL/CUL (CSA)/CE Approved
