Altec AC45 Series - Function Keys (Soft Keys)

Operation
4.2.1 Function keys (soft keys)
The F1-F12 key functions are displayed with assigned symbols:
Example
Function ke
ys with no assigned symbol are not active:
The function key symbols are normally blue.
Function key colors
Certain statuse
s are indicated by the change in color:
Examples
Grey
Significance here: no geometrical limit programmed
Green Significance here: Operational mode selection valid
Yellow Significance here: Operational mode selection not valid
Red Significance here: Outside a user limit
