11
3. BASIC SET UP- HDMI
Uses the HDMI connector on the back of the receiver to provide a complete
digital video and audio connection in one neat cable. A HDMI cable of
length to suit your purpose is required. All video outputs are active.
3.1. Prepare your equipment
Ensure the power leads to both display and receiver are unplugged whilst
making your AV connections. Your TV must have a HDMI input.
3.2. Connect the antenna…
to the “ANTENNA IN” socket on the rear of your receiver.
3.3. Mains Power
Turn on your set top at the mains power & you are ready to scan.
Video and Audio share the one HDMI cable
4. BASIC SETUP. HOME THEATRE
For this Set Up use your preferred video connection, the example below
shows video connection via YPbPr, you can use other methods from the
previous examples. You will also need an optical fiber cable for the audio.
All of video output modes are ready.
4.1 Prepare your equipment
