Altera Corporation Reference Manual 2–29
October 2006 Cyclone II FPGA Starter Development Board
Development Board Components
GPIO_0[4] PIN_A15 GPIO Connection 0[4]
GPIO_0[5] PIN_B15 GPIO Connection 0[5]
GPIO_0[6] PIN_A16 GPIO Connection 0[6]
GPIO_0[7] PIN_B16 GPIO Connection 0[7]
GPIO_0[8] PIN_A17 GPIO Connection 0[8]
GPIO_0[9] PIN_B17 GPIO Connection 0[9]
GPIO_0[10] PIN_A18 GPIO Connection 0[10]
GPIO_0[11] PIN_B18 GPIO Connection 0[11]
GPIO_0[12] PIN_A19 GPIO Connection 0[12]
GPIO_0[13] PIN_B19 GPIO Connection 0[13]
GPIO_0[14] PIN_A20 GPIO Connection 0[14]
GPIO_0[15] PIN_B20 GPIO Connection 0[15]
GPIO_0[16] PIN_C21 GPIO Connection 0[16]
GPIO_0[17] PIN_C22 GPIO Connection 0[17]
GPIO_0[18] PIN_D21 GPIO Connection 0[18]
GPIO_0[19] PIN_D22 GPIO Connection 0[19]
GPIO_0[20] PIN_E21 GPIO Connection 0[20]
GPIO_0[21] PIN_E22 GPIO Connection 0[21]
GPIO_0[22] PIN_F21 GPIO Connection 0[22]
GPIO_0[23] PIN_F22 GPIO Connection 0[23]
GPIO_0[24] PIN_G21 GPIO Connection 0[24]
GPIO_0[25] PIN_G22 GPIO Connection 0[25]
GPIO_0[26] PIN_J21 GPIO Connection 0[26]
GPIO_0[27] PIN_J22 GPIO Connection 0[27]
GPIO_0[28] PIN_K21 GPIO Connection 0[28]
GPIO_0[29] PIN_K22 GPIO Connection 0[29]
GPIO_0[30] PIN_J19 GPIO Connection 0[30]
GPIO_0[31] PIN_J20 GPIO Connection 0[31]
GPIO_0[32] PIN_J18 GPIO Connection 0[32]
GPIO_0[33] PIN_K20 GPIO Connection 0[33]
GPIO_0[34] PIN_L19 GPIO Connection 0[34]
GPIO_0[35] PIN_L18 GPIO Connection 0[35]
GPIO_1[0] PIN_H12 GPIO Connection 1[0]
GPIO_1[1] PIN_H13 GPIO Connection 1[1]
Table 2–14. Expansion Header FPGA Pin Connections (Part 2 of 3)
Signal Name FPGA Pin Description
