2–30 Reference Manual Altera Corporation
Cyclone II FPGA Starter Development Board October 2006
Development Board Components
GPIO_1[2] PIN_H14 GPIO Connection 1[2]
GPIO_1[3] PIN_G15 GPIO Connection 1[3]
GPIO_1[4] PIN_E14 GPIO Connection 1[4]
GPIO_1[5] PIN_E15 GPIO Connection 1[5]
GPIO_1[6] PIN_F15 GPIO Connection 1[6]
GPIO_1[7] PIN_G16 GPIO Connection 1[7]
GPIO_1[8] PIN_F12 GPIO Connection 1[8]
GPIO_1[9] PIN_F13 GPIO Connection 1[9]
GPIO_1[10] PIN_C14 GPIO Connection 1[10]
GPIO_1[11] PIN_D14 GPIO Connection 1[11]
GPIO_1[12] PIN_D15 GPIO Connection 1[12]
GPIO_1[13] PIN_D16 GPIO Connection 1[13]
GPIO_1[14] PIN_C17 GPIO Connection 1[14]
GPIO_1[15] PIN_C18 GPIO Connection 1[15]
GPIO_1[16] PIN_C19 GPIO Connection 1[16]
GPIO_1[17] PIN_C20 GPIO Connection 1[17]
GPIO_1[18] PIN_D19 GPIO Connection 1[18]
GPIO_1[19] PIN_D20 GPIO Connection 1[19]
GPIO_1[20] PIN_E20 GPIO Connection 1[20]
GPIO_1[21] PIN_F20 GPIO Connection 1[21]
GPIO_1[22] PIN_E19 GPIO Connection 1[22]
GPIO_1[23] PIN_E18 GPIO Connection 1[23]
GPIO_1[24] PIN_G20 GPIO Connection 1[24]
GPIO_1[25] PIN_G18 GPIO Connection 1[25]
GPIO_1[26] PIN_G17 GPIO Connection 1[26]
GPIO_1[27] PIN_H17 GPIO Connection 1[27]
GPIO_1[28] PIN_J15 GPIO Connection 1[28]
GPIO_1[29] PIN_H18 GPIO Connection 1[29]
GPIO_1[30] PIN_N22 GPIO Connection 1[30]
GPIO_1[31] PIN_N21 GPIO Connection 1[31]
GPIO_1[32] PIN_P15 GPIO Connection 1[32]
GPIO_1[33] PIN_N15 GPIO Connection 1[33]
GPIO_1[34] PIN_P17 GPIO Connection 1[34]
GPIO_1[35] PIN_P18 GPIO Connection 1[35]
Table 2–14. Expansion Header FPGA Pin Connections (Part 3 of 3)
Signal Name FPGA Pin Description
