Altera tPad DE2-115 - Page 17

16
CAMERA_ D3
PIN_G26
Pixel data bit 3
2.5V
CAMERA_ D4
PIN_H25
Pixel data bit 4
2.5V
CAMERA_ D5
PIN_H26
Pixel data bit 5
2.5V
CAMERA_ D6
PIN_K25
Pixel data bit 6
2.5V
CAMERA_ D7
PIN_K26
Pixel data bit 7
2.5V
CAMERA_ D8
PIN_L23
Pixel data bit 8
2.5V
CAMERA_ D9
PIN_L24
Pixel data bit 9
2.5V
CAMERA_ D10
PIN_M25
Pixel data bit 10
2.5V
CAMERA_ D11
PIN_M26
Pixel data bit 11
2.5V
CAMERA_ STROBE
PIN_G28
Snapshot strobe
2.5V
CAMERA_ LVAL
PIN_K27
Line valid
2.5V
CAMERA_ FVAL
PIN_K28
Frame valid
2.5V
CAMERA_ RESET_N
PIN_M28
Image sensor reset
2.5V
CAMERA_ SCLK
PIN_K22
Serial clock
2.5V
CAMERA_ TRIGGER
PIN_H23
Snapshot trigger
2.5V
CAMERA_ SDATA
PIN_H24
Serial data
2.5V
CAMERA_ XCLKIN
PIN_G23
External input clock
2.5V
