Altera tPad DE2-115 - 1.1 About the Kit

6
Table 1-2 Key performance parameters of the CMOS sensor
Parameter
Value
Active Pixels
2592Hx1944V
Pixel size
2.2umx2.2um
Color filter array
RGB Bayer pattern
Shutter type
Global reset release(GRR)
Maximum data rate/master clock
96Mp/s at 96MHz
Frame rate
Full resolution
Programmable up to 15 fps
VGA mode
Programmable up to 70 fps
ADC resolution
12-bit
Responsivity
1.4V/lux-sec(550nm)
Pixel dynamic range
70.1dB
SNRMAX
38.1dB
Supply Voltage
Power
3.3V
I/O
1.7V～3.1V
Note: for more detailed information of the LCD touch panel and CMOS sensor module,
please refer to their datasheets respectively.
1
1
.
.
1
1
A
A
b
b
o
o
u
u
t
t
t
t
h
h
e
e
K
K
i
i
t
t
The kit contains all users needed to run the demonstrations and develop custom designs, as shown
in Figure 1-2.
The system CD contains technical documents of the tPad which includes component datasheets,
demonstrations, schematic, and user manual.
