5
 Power
o Desktop DC input
o Switching and step-down regulators LM3150MH
 LCD touch screen module
 Equipped with an 8-inch Amorphous-TFT-LCD (Thin Film Transistor Liquid Crystal Display)
module
 Module composed of LED backlight
 Support 18-bit parallel RGB interface
 Converting the X/Y coordination of touch point to its corresponding digital data via the
Analog Devices AD7843 A/D converter
Table 1-1 shows the general physical specifications of the LTC (Note*).
Table 1-1 General physical specifications of the LCD
Item
Specification
Unit
LCD size
8 inch (Diagonal)
-
Resolution
800 x3(RGB) x 600
dot
Dot pitch
0.0675(W) x 0.2025(H)
mm
Active area
162.0(W) x 121.5(H)
mm
Module size
183.0(W) x 141.0(H) x 7.2(D)
mm
Surface treatment
Anti-Glare
-
Color arrangement
RGB-stripe
-
Interface
Digital
-
 5-Megapixel digital image sensor module
 Superior low-light performance
 High frame rate
 Low dark current
 Global reset release, which starts the exposure of all rows simultaneously
 Bulb exposure mode, for arbitrary exposure times
 Snapshot mode to take frames on demand
 Horizontal and vertical mirror image
 Column and row skip modes to reduce image size without reducing field-of-view
 Column and row binning modes to improve image quality when resizing
 Simple two-wire serial interface
 Programmable controls: gain, frame rate, frame size, exposure
Table 1-2 shows the key parameters of the CMOS sensor (Note*).
