Audio
o 24-bit encoder/decoder (CODEC)
o Line-in, line-out, and microphone-in jacks
Display
o 16x2 LCD module
On-Board Clocking Circuitry
o Three 50MHz oscillator clock inputs
o SMA connectors (external clock input/output)
SD Card Socket
o Provides SPI and 4-bit SD mode for SD Card access
Two Gigabit Ethernet Ports
o Integrated 10/100/1000 Gigabit Ethernet
High Speed Mezzanine Card (HSMC)
o Configurable I/O standards (voltage levels: 3.3/2.5/1.8/1.5V)
USB Type A and B
o Provide host and device controller compliant with USB 2.0
o Support data transfer at full-speed and low-speed
o PC driver available
40-pin Expansion Port
o Configurable I/O standards (voltage levels: 3.3/2.5/1.8/1.5V)
VGA-out Connector
o VGA DAC (high speed triple DACs)
DB9 Serial Connector
o RS232 port with flow control
PS/2 Connector
o PS/2 connector for connecting a PS2 mouse or keyboard
TV-in Connector
o TV decoder (NTSC/PAL/SECAM)
Remote Control
o Infrared receiver module
