 Run the Nios II Software under the workspace tPad_Picture_Viewer\Software (Note*)
 Touch the play button will proceed to display the next image. Figure 4-8 gives a screen shot of
the tPad picture viewer demonstration. Table 4-1 shows the instructions for running the
demonstration
Figure 4-8 tPad picture viewer demonstration
Table 4-1 Touch panel displayed information
Display information
Implication
Press the play button to display the next buffered image
Indicates the loading progress
Note: execute the tPAD_Picture_Viewer.bat under tPAD_Picture_Viewer\demo_batch will
automatically download the .sof and .elf file.
