MN-29423 • Rev 6 • 02/18 • S-Series Hot Food Holding Cabinets 13
Installation
How to Install the Drip Tray
Failure to properly install the
drip tray can or will cause major
equipment damage and will
result in a leakage hazard that
can cause personal injury.
Item Description Qty
A Double-sided tape 1
B Drip tray holder 1
C Screw, 8-32 x 1/4" Philips 3
D Drip tray 1
1. Poke holes through the double-sided tape A which is attached to the back of the drip tray holder B.
2. Remove the backing on the double-sided tape A.
3. Put the screws C through the holes and attach the drip tray holder B to the front of the appliance.
4. Optional - apply a line of food-grade silicone caulk along the top edge of the drip tray holder B to seal.
5. Place the drip tray D in the drip tray holder B.
A
B
C
D
