INSTALLATION
Dra wer Wa rmer ▪ Oper a tor’s M a n ual ▪ M N-46969 ▪ Rev 1 ▪ 5/ 2 0
18
How to Unpack the Appliance
Before you begin Make sure you have:
▪ An appropriate lifting device and enough personnel to safely move and position
the weight of the appliance.
□ 500-1D: 80 lbs (36 kg)
□ 500-2D, 500-2DI: 115 lbs (52 kg)
□ 500-3D: 150 lbs (68 kg)
□ 500-1DN: 67 lbs (30 kg)
□ 500-2DN: 100 lbs (45 kg)
□ 500-3DN: 130 lbs (59 kg)
▪ Cutting tools to remove the packaging.
Unpack the appliance To unpack the appliance, do the following.
Step Action
1. Remove the box. Save all packing materials for inspection by the carrier.
2. Remove the shrink wrap.
3. Cut the restraining straps.
4. Remove the appliance from the pallet.
Result The appliance is now unpacked.
NOTE: Examine the appliance for damage. If the appliance
has been damaged, do not use the appliance until it has
been inspected by an authorized service provider. Contact
your carrier or Alto-Shaam
®
customer service.
