Operation and Care Manual #861
7
SERVICE VIEW PARTS LIST: CH-75/DM
U N I T ALTO-SHAAM
PART DESCRIPTION QTY PART NUMBER
U N I T ALTO-SHAAM
PART DESCRIPTION QTY PART NUMBER
1. TOP ASSEMBLY 1 4174
2. TOP ASSEMBLY MOUNTING SCREWS 5 SC-2425
3. TUBE TOP MOUNTING SCREWS 2 SC-2332
4. TUBE BOTTOM MOUNTING SCREWS 2 SC-2425
BOTTOM FILLER (NOT SHOWN) 1 1002
TRIM TO BOTTOM FILLER MOUNTING SCREWS 2 SC-2425
CAPILLARY BULB GUARD (NOT SHOWN) 2 GD-2450
BULB GUARD MOUNTING SCREWS (NOT SHOWN) 4 SC-2425
BULB MOUNTING SCREWS (NOT SHOWN) 4 SC-2077
BULB HOLD-DOWN (NOT SHOWN) 4 BK-2609
CAPILLARY BULB (NOT SHOWN)2—
LAMP GUARD (NOT SHOWN) 1 1056
LAMP GUARD MOUNTING SCREWS (NOT SHOWN) 2 SC-2459
LAMP GUARD MOUNTING SCREWS (NOT SHOWN) 2 SC-2268
LAMP (120/208-240V) 1 LP-3480
LAMP (220V) 1 LP-3606
5. HOLD THERMOSTAT KNOB (FAHRENHEIT) 1 KN-3469
HOLD THERMOSTAT KNOB (CELSIUS) 1 KN-3474
6. COOK THERMOSTAT KNOB (FAHRENHEIT) 1 KN-3468
COOK THERMOSTAT KNOB (CELSIUS) 1 KN-3475
7. COOK TIMER KNOB 1 —
COOK TIMER NUT 1 —
8. POWER SWITCH NUT 1 NU-2355
9. BELL TIMER KNOB 1 —
10. LAMP SWITCH NUT 1 NU-2355
11. CONTROL PANEL 1 4603
12. CONTROL PANEL MOUNTING SCREWS 1 SC-2459
CONTROL PANEL MOUNTING SCREWS 5 SC-2425
13. CABLE COVER 2 1324
14. CABLE COVER MOUNTING SCREWS 4 SC-2425
15. TUBE ASSEMBLY 1 5450
16. CASING ASSEMBLY 1 4601
17. INSULATION TUBE ASSEMBLY (LEFT-HAND) 1 4170
18. INSULATION TUBE (
RIGHT-HAND) 1 1163
19. INSULATION TUBE MOUNTING SCREWS 6 SC-2059
20. INSULATION: Size 25" x 120" (635-mm x 3048-mm) 1 IN-2381
21. CABLE CONNECTION HARDWARE:
— SHOULDER BUSHING 6 BU-3105
— CUP BUSHING 6 BU-3106
— HEX NUT 36 NU-2215
— RING CONNECTOR 6 CR-3226
— STUD 6 ST-2439
22. HEATING CABLE: Length 191' (58217mm) 1 CB-3045
23. DOOR ASSEMBLY (
RIGHT-HAND) 1 5452
DOOR ASSEMBLY (LEFT-HAND) 1 5471
24. HINGE SET (1 set of 2 pairs) 1 HG-2014
HINGE TO DOOR MOUNTING SCREWS (NOT SHOWN) 6 SC-2072
HINGE TO UNIT MOUNTING SCREWS (NOT SHOWN) 6 SC-2073
25. DOOR HANDLE 1 HD-2566
DOOR HANDLE MOUNTING SCREWS (NOT SHOWN) 4 SC-2073
DOOR CATCH MOUNTING SCREWS (NOT SHOWN) 2 SC-2162
26. DOOR GASKET: Length 8' (2438mm) 1 GS-2398
27. SHELVES 3 SH-2324
28. SIDE RACK 2 SR-2303
29. DRIP PAN 1 14831
30. BELL TIMER 1 TR-22388
31. HOLD THERMOSTAT 1 TT-3057
32. POWER SWITCH 1 SW-3528
33. PILOT LIGHT 3 LI-3025
34. COOK TIMER (120/208-240V) 1 TR-3318
COOK TIMER (220V) 1 TR-3402
35. COOK THERMOSTAT 1 TT-3329
36. LAMP SWITCH 1 SW-3041
37. CONTACTOR 1 CN-3052
38. FAN 2 FA-3342
FAN BLADE 2 FA-3343
39. VOLTAGE CONVERSION SWITCH 1 SW-3528
40. SWITCH BOX COVER 1 11133
41. SWITCH BOX COVER MOUNTING SCREWS 2 SC-2459
42. DRIP TRAY 1 11258
43. DRIP TRAY HOLDER 1 11259
44. DRIP TRAY HOLDER SCREWS 3 SC-2425
11/5/99
High Temperature Cable Kit #4881 (208-240V)
Item Description Quantity
CB-3045 Cable Heating Elements 200 feet
CR-3226 Ring Connector 6
IN-3488 Insulation Corner 8 feet
BU-3105 Shoulder Bushing 6
BU-3106 Cup Bushing 6
SL-3063 Insulating Sleeve 6
TA-3540 High Temperature Tape 30 feet
Note: Cables are creme or white cloth material.
