MN-29742 (Rev. 6) 02/16 • Drawer Warmers • 20
9
21
23
10
8
27
30
26
25
13
24
31
32
18
29
28
20
3
19
16 7
14
5
11
17
4
12
1
15
6
2
22
9
21
23
10
8
27
30
26
25
13
24
31
32
18
29
28
20
3
19
16 7
14
5
11
17
4
12
1
15
6
2
22
Item Part Descriptio
ty
1 1008272 BRACKET, SENSOR MTG. 1
2 1012779 TOP COVER 1
IN-2003 INSULATION 1
4 BK-29606 CONTROL SENSOR BLOCK 1
5 CC-34970 WARMER CONTROL 1
6 GS-23622 GASKET ADHESIVE 0.125 x 0.375 [lin ft] 1
7 NU-2361 NUT, 6-32 HEX, S/S
8 1012778 INNER BACK PANEL, 500-3DN 1
1012790 INNER BACK PANEL, 500-2DN 1
1012797 INNER BACK PANEL, 500-1DN 1
9 1012777 OUTER CASING, 500-3DN 1
1012792 OUTER CASING, 500-2DN 1
1012795 OUTER CASING, 500-1DN 1
10 1012781 REAR TRIM, 500-3DN
1012791 REAR TRIM, 500-2DN
1012796 REAR TRIM, 500-1DN
11 PE-29686 PANEL OVERLAY 1
12 PR-34494 PROBE 1
13 SC-22271 SCREW, M4-0.7 x 6mm PHIL
14 BG-24890 BEARING, DRAWER WARMER 6
15 SC-2459 SCREW, 8-32 x 1/4" PHIL SCREW 4
16 WS-23148 WASHER, 6-32, FLAT, NYL 4
17 SW-34769 SWITCH, ROCKER, 125-277V, 20A 1
18 WS-2467 WASHER, INT. LOCK 1
19 EL-29738 ELEMENT, 320W, FOIL PAD HEATER 2
20 SC-25018 SCREW, 1/4-20 x 1-1/8" FLAT HD 6
21 RI-2100 RIVET, BLIND, #44, STAINLESS 14
22 5014435 DRAWER FRAME ASSEMBLY 3
5014561 DRAWER FRAME ASSEMBLY, VENTED 1
23 5014426 TUBE SPOT ASSEMBLY, 500-3DN 1
5014428 TUBE SPOT ASSEMBLY, 500-2DN 1
5014431 TUBE SPOT ASSEMBLY, 500-1DN 1
24 1003936 HI-LIMIT PROTECTION COVER 1
25 BK-3019 T-BLOCK 1
26 BU-3964 BUSHING, STRAIGHT, STRAIN RELIEF 1
27 CD-3232 CORDSET, 14/3 SJTOW, 125V 1
28 CR-34646 CONNECTOR-5 CONDUCTOR 2
29 SC-36973 SCREW, PAN PH, METRIC, M5 1
30 PG-25574 3/8" HOLE PLUG 1
31 TT-33476 THERMOSTAT, 300F HI-LIMIT 1
32 SC-2365 SCREW, 6-32 x 1-1/4" ROUND HEAD 2
4
1
1
1
2
3
