MN-38954 • Rev 0 • 04/17 • Quickchillers 13
Dimensions
QC3-20
36" (914mm)
57" (1448mm)
57-1/2" (1461mm)
8-1/8" to 9-1/4"
(216mm to 235mm)
35-5/8" to 37-1/2"
(905mm to 953mm)
41-1/2" to 42-5/8"
(1054mm to 1083mm)
Weight
Net: Contact factory Ship: 450 lb (204 kg)
Carton dimensions: (L x W x H)
60" x 39" x 48-1/2" (1524mm x 991mm x 1232mm)
Refrigeration
40 oz. R404a Refrigerant
One (1) 3/4 hp Condensing Unit:
Freeze mode: 4,380 BTU's per hour at -5°F (-21°C)
Chill mode: 7,080 BTU's per hour at +20°F (-7°C)
Product/Pan Capacity
Maximum chilling capacity (approx.) 60 lb (27 kg)
Maximum volume 37.5 quarts (47,5 liters)
Full-size pans
20" x 12" x 2-1/2"
Five (5)
Gastronorm 1/1
530mm x 325mm x 65mm
Three (3)
Full-size sheet pans
18" x 26" x 1"
Nine (9)
