12 MN-38954 • Rev 0 • 04/17 • Quickchillers
Dimensions
27" (686mm)
30" (762mm)
Electrical Connection
Cord Length: 9'(2743mm)
55-3/4" (1416mm)
3-5/8" to 4-3/4" (92mm to 121mm)
37-7/8" to 39" (962mm to 991mm)
QC3-3
Weight
Net: Contact factory Ship: 330 lb (150 kg)
Carton dimensions: (L x W x H)
35" x 35" x 42" (889mm x 889mm x 1067mm)
Refrigeration
40 oz. R404a Refrigerant
One (1) 1/2 hp Condensing Unit:
Freeze mode: 2,800 BTU's per hour at -5°F (-21°C)
Chill mode: 4,750 BTU's per hour at +20°F (-7°C)
Product/Pan Capacity
Maximum chilling capacity (approx.) 36 lb (16 kg)
Maximum volume 22-1/2 quarts (28,5 liters)
Full-size pans
20" x 12" x 2-1/2"
Three (3)
Gastronorm 1/1
530mm x 325mm x 65mm
Three (3)
