INSTALLATION
Ve ct or F ® Se ries ▪ O pera to r’s Man ual ▪ MN-468 94 ▪ Rev 1 ▪ 7/2 0
32
How to Install the Oven (Canada Models Only)
Before you begin Make sure you have:
▪ Screwdriver (Phillips #2)
▪ Nut driver (1/4-inch)
▪ Spirit (bubble) level
▪ An appropriate lifting device and enough personnel to safely move and position
the weight of the oven.
□ VMC-F3E: 489 lb (222 kg)
□ VMC-F4E: 616 lb (279 kg)
Requirements ▪ The oven must be installed on a level surface.
▪ The oven must not be installed in any area where it may be affected by:
□ steam
□ grease
□ dripping water
□ high temperature
□ any other severely adverse conditions
▪ The oven is not intended for built-in installation.
Voltages
Continued on next page
V Ph Hz A Breaker* kW
VMC-F3E 208–240 3 60 31–35 50 11.5–15.0
VMC-F4E 208–240 3 60 41–46 60 15.2–19.9
*Electrical connections must meet all applicable federal and local codes.
