INSTALLATION
Ve ct or F ® Se ries ▪ O pera to r’s Man ual ▪ MN-468 94 ▪ Rev 1 ▪ 7/2 0
39
How to Install the Oven on a Mobile Base
Before you begin Make sure you have:
▪ An appropriate lifting device and enough personnel to safely move and position
the weight of the oven.
□ VMC-F3E: 489 lb (222 kg)
□ VMC-F4E: 616 lb (279 kg)
▪ Regulation UL 197, 91.8
Procedure To install the oven on a mobile base, do the following.
Step Action
1. Remove the feet a.
2. Remove the 4 nuts b from the mobile base.
Continued on next page
NOTE: The 4 nuts can be discarded. The nuts are only
needed during the shipping process.
