INSTALLATION
Ve ct or F ® Se ries ▪ O pera to r’s Man ual ▪ MN-468 94 ▪ Rev 1 ▪ 7/2 0
26
How to Install the Oven
(60 Hz Models Without Cords or Plugs)
Before you begin Make sure you have:
▪ Screwdriver (Phillips #2)
▪ Nut driver (1/4-inch)
▪ Spirit (bubble) level
▪ An appropriate lifting device, and enough personnel, to safely move and position
the weight of the oven.
□ VMC-F3E: 489 lb (222 kg)
□ VMC-F4E: 616 lb (279 kg)
Requirements ▪ The oven must be installed on a level surface.
▪ The oven must not be installed in any area where it may be affected by steam,
grease, dripping water, high temperature, or any other severely adverse
conditions.
▪ The oven is not intended for built-in installation.
Voltages
Continued on next page
V Ph Hz A Breaker* kW
VMC-F3E 208–240 3 60 31–35 50 11.5–15.0
VMC-F4E 208–240 3 60 41–46 60 15.2–19.9
*Electrical connections must meet all applicable federal, state, and local codes.
