3. CONTROL ELEMENTS
It will flash when you are reaching the maximum power output of the amplifier.
It should flash only occasionally for optimum operation.
Front Panel:
1 Power On LED
This green LED will light up when you switch the A400.4 ON.
2 Power Switch
To switch the A400.4 ON and OFF.
3 Level Control for Channels1,2,3&4
Adjust the output signal level of the respective channel.
4 Clip LED
5 Limit LED
This LED will flash when the internal limiter is operating.
The limiter will prevent distortion and will protect the life of high frequency
transducers.
6 Signal LED
When a signal is applied to the input of your A400.4, this LED will light up.
