Alto AMX-100 Owner's Manual

9. TECHNICAL SPECIFICATION
Mono input channels
Gain range
0 dB to 44 dB (MIC)
SNR (Signal to Noise Ratio)
115 dB
Line input
electronically balanced
Frequency response
10 Hz to 55 kHz, +/ 3 dB
Distortion (THD & N)
0.005% at 4 dBu, 1 kHz+
Sensitivity range
+15 dBu to 30 dBu
Microphone input
Electronically balanced, discrete input configuration
Frequency response
10 Hz to 55 kHz, +/ 3 dB
Distortion (THD & N)
0.005% at 4 dBu, 1kHz+
Stereo input channels
Line input
Balanced
Frequency response
10 Hz to 55 kHz,
+
/3dB
Distortion (THD & N)
0.005% at +4 dBu, 1 kHz
Impedances
Microphone input
1.4k Ohm
All other inputs
10k Ohm or greater
Tape out
1k Ohm
All other output
120 Ohm
Equalization
Hi shelving
+/ 15 dB @12 kHz
Mid bell
+/ 12 dB @2.5 kHz
Low shelving
+/ 15 dB @80 Hz
Low Cut filter
75 Hz, 18 dB/oct.
DSP Section (For AMX-100FX Model)
A/D and D/A converters
24 bit
DSP resolution
24 bit
Type of effects
Hall, Room, Vocal & Plate REVERBS
Mono & Stereo DELAY (max DELAY TIME 650ms)
Chorus, Flanger & Reverb MODULATIONS
REVERB+DELAY, REVERB+CHORUS,
Presets
256
Controls
16-position PRESET Selector
16-position VARIATION selector
PEAK LED
MUTE SWITCH with LED indicator
REVERB+FLANGER combinations
Main Mix Section
Noise (Bus noise) Fader 0 dB, channels muted:
100 dBr (ref.:+4 dBu)
Fader 0 dB, all input channels assigned and set to
UNITY gain: 90 dBr (ref.:+4 dBu)
Max output
22 dBu unbalanced, 1/4" jacks+
AUX Returns gain range
- to +15 dB
AUX Sends max out
+22 dBu
15
