Alto Elvis Series User Manual

9
-. ACTIVE SUBWOOFER Speaker for ELVIS12 SA / ELVIS15 SA
(1) Bi-polar main power switch.
(2) Input AC power socket with main fuse.
(3) Ground Swicth.
(4) POWER, blue LED, indicate ON status.
(5) SIGN / COMP, signal/compressor, green/red LED
(6)
(7)
(8) VOLUME main power amplifier control.
(9)
(10)
LEFT signal output on XLR or Jack connector for active satellite, under electronic crossover at 125Hz.
RIGHT on XLR connector for active satellite, under electronic crossover at 125Hz.
RIGHT, input signal on XLR connector.
LEFT/MONO, input signal on COMBO connector.
GND
ON
OFF
AC INPUT: 230V~ 50Hz
RIGHT
LEFT/
MONO
RIGHT
LEFT/
MONO
LINK
OUT
IN
VOLUME
+4dBu
SIGN
COMP
SERIAL
MODEL
POWER
-
(1)(2)
(3)
(4)
(5)
(7)
(6)
(8)
(9)
(10)
Use only with a 250V fuse
PUSH
2
1
3
NEW
TIDE
PUSH
1
3
2
NEW
TIDE
