3. CONNECTION PLATE
- PASSIVE FULL-RANGE Speaker for ELVIS10 / ELVIS12 / ELVIS15 / ELVIS12M
(1) INPUT: Receive the power coming from an external power amplifier (SPK +1/-1 connected; +2/-2 not connected).
(2) THRU: Direct LINK for connect in parallel a second speaker cabinet (SPK +1/-1 connected; +2/-2 not connected).
INPUT THRU
LINK
LTO
R
ELVIS 12
SOUND REINFORCEMENT SPEAKER SYSTEM
DESIGNED AND DEVELOPMENT IN ITALY
Power Handling:
AES-180Watts
PEAK- 360Watts
IMPEDANCE:
8 ohms nominal
SERIAL
MODEL
7
(1)
(2)
- PASSIVE SUBWOOFER Speaker for ELVIS12S / ELVIS15S
(1) INPUT: Receive the power (SPK +1/-1 connected;+2/-2 not connected).coming from an external amplifier
(2) OUTPUT: Power output for satellite speaker, under passive crossover filtered at 125Hz (SPK +1/-1 connected;
+2/-2 not connected).
INPUT OUTPUT
LTO
R
ELVIS 12S
DESIGNED AND DEVELOPMENT IN ITALY
POWER HANDLING:
AES-200Watts
PEAK - 400 Watts
IMPEDANCE:
4 ohms nominal
SERIAL
MODEL
(1) (2)
