9. TECHNICAL SPECIFICATION
Mono input channels
Microphone input electronically balanced, discrete input configuration
Frequency response 10Hz to 55kHz, + 3dB
Distortion (THD & N) 0.005% at +4dBu, 1kHz
Gain range 0dB to 60dB (MIC)
SNR (Signal to Noise Ratio) 115dB
Line input electronically balanced
Frequency response 10Hz to 55kHz, + 3dB
Distortion (THD & N) 0.005% at +4dBu, 1kHz
Sensitivity range + to 45dBu
15dBu
Stereo input channels
Line input unbalanced
Frequency response 10Hz to 55kHz,
+
3dB
Distortion (THD & N) 0.005% at +4dBu, 1kHz
Impedances
Microphone input 1.4kOhm
Channel Insert return 2.5kOhm
All other inputs 10kOhm or greater
Tape out 1kOhm
All other output 120Ohm
Equalization
Hi shelving + @12kHz15dB
Mid bell + @2.5kHz
12dB
Low shelving + @80Hz
15dB
Low Cut filter 75Hz, 18dB/oct.
Main Mix Section
Noise (Bus noise) Fader 0 dB, channels muted: 100dBr (ref.:+4dBu)
Fader 0dB, all input channels assigned
and set to UNITY gain: 90dBr (ref.:+4dBu)
Max output + balanced XLR,22dBu
22dBu unbalanced, 1/4" jacks+
AUX Return gain range OFF to +15dB
AUX Sends max out +22dBu
DSP SECTION
A/D and D/A converters 24 bit
DSP resolution 24 bit
Type of effects Hall, Room, Vocal & Plate REVERBS
Mono & Stereo DELAY (max DELAY TIME 650ms)
Chorus, Flanger & Reverb MODULATIONS
REVERB+DELAY, REVERB+CHORUS, REVERB+FLANGER combinations
Presets 256
Controls 16-position PRESET Selector
16-position VARIATION selector
CLIP LED
MUTE SWITCH with LED indicator
