IN THIS MANUAL:
1. INTRODUCTION..............................................................................1
2. FEATURES.....................................................................................1
3. CONTROL ELEMENTS...................................................................5
4. OPERATION...................................................................................8
5. BLOCK DIAGRAM........................................................................11
6. TECHNICAL SPECIFICATIONS.......................................................12
7. WARRANTY.................................................................................13
1. INTRODUCTION
Thank you for expressing your confidence in products by purchasing one of
our MAC 2 Series stereo amplifiers. The MAC 2 series include MAC 2.2, MAC
2.3 and MAC 2.4. All models are rugged, 2 rack-unit stereo amplifiers fan-cooled.
Despite their compact dimensions they provide a lot of power and a high value
performance. They are all designed for heavy-duty application and they all can drive
2 ohm loads for long periods without overheating. Therefore they are suited to drive
subwoofers with a minimum load of 4 ohms when working in Bridge Mode.
LT O
2. FEATURES
Clip-limiter circuit that is user-adjustable
Switchable low-frequency filter at 30Hz
Operating Mode is: Stereo, Parallel or Bridge
Balanced XLR and 1/4" TRS input connectors
Output connectors are speak-on jacks and binding post terminals
Low-noise, variable speed fan
Front panel LED indicating Signal and Clipping and Protection Status
Manufactured under QS9000, VDA6.1 certified management system
1
