Alto MIXPACK 10 User Manual

45
Mixer
Input Channels
Microphone Input Electronically balanced, discrete input
Frequency Response: 20 Hz – 22 kHz (+3 dB)
Gain: 55 dB
Line Input Electronically balanced, discrete input
Frequency Response: 20 Hz – 22 kHz (+3 dB)
Gain: 10 dB
Impedance
Microphone Input
1.5
K
Ω
Line Inputs
10
K
Ω or greater
Record Out
1
K
Ω
Monitor Outputs
120 Ω
Equalization
High Shelving +14 dB @ 12 kHz
Low Shelving +14 dB @ 80 kHz
Main Mix Section
Monitor Output +22 dBu unbalanced, 1/4” jack
Record Output +22 dBu unbalanced, coaxial
Power Amplifier
Output Power 200 W RMS @ 1 kHz
THD 1%, 4-Ω load
Frequency Response
20 Hz – 22 kHz, +3 dB
Power
100–120 / 220–240 V; 50/60 Hz
Dimensions
(width x depth x height)
5.75" x 2.5"x 11"
14.6 cm x 6.4 cm x 27.9 cm
Weight
4.15 lbs.
1.9 kg

Alto MIXPACK 10 Specifications

General

Brand	Alto
Model	MIXPACK 10
Category	Speakers
Language	English
