4
Quick Start
Setup
Connect cables with all equipment powered off, and ensure that all main volume controls are
turned down. Follow the procedure below to have a signal processed for each channel:
1. Set all channel Level knobs to zero, set the Main Level knob to zero, and set EQ’s flat.
2. Connect your mic and then engage the Phantom Power switch if your mic requires this.
3. Set the Main Level knob to no more than 70% and the Monitor knob at minimum.
4. Adjust the channel Level knob and bring up the Monitor knob slowly to reach the desired
level.
5. Repeat Steps 1 and 2 to set up more channels.
Connection Diagram
Items not listed under Introduction > Box Contents are sold separately.
Guitar
Microphone
Mixpack 10 Loudspeakers
Synthesizer
Recorder
Powered
Loudspeaker
To Next Page
