Alto ts115a truesonic User Manual

SPECIFICATIONS
Output Power: 400 W Continuous RMS (335 W LF Class D + 65 W HF Class AB)
800 W Peak (670 W LF + 130 W HF)
Crossover: 2 kHz
Max SPL @ 1m: 122 dB Continuous, 125 dB Peak
Frequency Response: 48 Hz – 18 kHz (@ -10 dB)
Low Frequency: 15" (381 mm) woofer, 2" (51 mm) voice coil
High Frequency: 1" (25 mm) neodymium driver
Coverage: 80°/100° H x 60° V nominal
Connectors: Input: 1/4" TRS or XLR
Link: XLR
Cabinet: Polypropylene, trapezoidal
External Control: Volume control, power-on with LED, clip limiter with LED, ground lift
Power supply: 100-120V/220-240V, 50/60 Hz
Dimensions (H x W x D): 26.7" x 16.9" x 15.2" (679 mm x 430 mm x 385 mm)
Weight (speaker only): 48.6 lbs (22 kg)
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND (2)
THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY
CAUSE UNDESIRED OPERATION.
Inrush current at initial switch-on: 3.61 A
Inrush current after power supply interruption: 3.91 A
www.altoprofessional.com
MANUAL VERSION 1.4

Alto ts115a truesonic Specifications

Power

output power continuous	400 W
output power peak	800 W
power supply voltage	100-120V/220-240V
power supply frequency	50/60 Hz
inrush current at initial switch-on	3.61 A
inrush current after power supply interruption	3.91 A

Audio Specifications

crossover frequency	2 kHz
max SPL continuous	122 dB
max SPL peak	125 dB
frequency response	48 Hz – 18 kHz

Driver Specifications

low frequency driver size	15" (381 mm)
low frequency voice coil	2" (51 mm)
high frequency driver size	1" (25 mm)

Connectivity

input connector	1/4" TRS or XLR
link connector	XLR

Weight and Dimensions

dimensions (H x W x D)	26.7" x 16.9" x 15.2" (679 mm x 430 mm x 385 mm)
weight	48.6 lbs (22 kg)
