24.0 MODBUS REGISTER LIST
ADDRESS DESCRIPTION
40001
NULL
40002
Hourmeter; range from 0-65535
40004
STATUS: Manual Stop = 00, Fault on Channels 1-60 = 01-60, S01 = 151, S02 = 152, Overcrank = 165,
Serial Fault = 166, Pre-Lube Fault = 167, Cool-Down Shutdown = 168, Power Loss = 249, Startup Sequence
= 253, Timers Active = 254, Running = 255
40005
Output status; BIT0=OUT1, BIT1=OUT2, BIT2=OUT3, BIT3=OUT4
40006
Fault status; 0=NA, 1=Low Fault, 2=High fault
40020
Digital output status for terminal board #1 (Bitmap of outputs: 0 = Off, 1 = On)
40021
Digital output status for terminal board #2 (Bitmap of outputs: 0 = Off, 1 = On)
40029
Color of the DE-3000 display (1 = yellow/startup sequence, 2 = red/stop, 3 = white/not used, 4 = red/fault,
5 = green/running, 6 = yellow/timers active)
40030 –
40069
The ASCII characters of what is contained on the display of the DE-3000. The upper part of the register
displays the first character; the lower part displays the next character/ This may be used for MMI/MIDAS
applications.
40080
Writable register for the keypad input. Use function 6 to perform the write. See Key Press Table for the values
for each key. This register, along with 40030-40069, may be used in conjunction with a MMI/Red Lion to
press keys on the keypad.
40090
Channel #1 input reading (signed)
40091
Channel #2 input reading (signed)
40092
Channel #3 input reading (signed)
40093
Channel #4 input reading (signed)
40094
Channel #5 input reading (signed)
40095
Channel #6 input reading (signed)
40096
Channel #7 input reading (signed)
40097
Channel #8 input reading (signed)
40098
Channel #9 input reading (signed)
40099
Channel #10 input reading (signed)
40100
Channel #11 input reading (signed)
40101
Channel #12 input reading (signed)
40102
Channel #13 input reading (signed)
40103
Channel #14 input reading (signed)
40104
Channel #15 input reading (signed)
40105
Channel #16 input reading (signed)
40106
Channel #17 input reading (signed)
40107
Channel #18 input reading (signed)
40108
Channel #19 input reading (signed)
40109
Channel #20 input reading (signed)
4 0110
Channel #21 input reading (signed)
4 0111
Channel #22 input reading (signed)
