Altronic DE-3000+ Series - Page 46

DE-3000+ IOI 8-15
All rights reserved © ALTRONIC, LLC 2015
46
ADDRESS DESCRIPTION
40198
PID #2, I term; range 001-999 s (Writable)
40199
PID #2, D term; range 001-999 m (Writable)
40200
PID #1 control setpoint (Writable)
40201
PID #2 control setpoint (Writable)
40202
Indicates the time remaining for the test timer. The value is (-1) if not in test mode.
40203
Cool Down time left (s). 0 indicates not in Cool Down
40204
Cool Down time (s). Write anything to initiate Cool Down
40205
PID #3, P term; range 001-999% (Writable)
40206
PID #3, I term; range 001-999 s (Writable)
40207
PID #3, D term; range 001-999 m (Writable)
40208
PID #4, P term; range 001-999% (Writable)
40209
PID #4, I term; range 001-999 s (Writable)
40210
PID #4, D term; range 001-999 m (Writable)
4 0 211
PID #3 control setpoint (Writable)
40212
PID #4 control setpoint (Writable)
40213
Firmware month of display (1-12)
40214
Firmware day of display (1-31)
40215
Firmware year of display (00 – 99)
40216
Firmware month of 1st terminal (1-12)
40217
Firmware day of 1st terminal (1-31)
40218
Firmware year of 1st terminal (00 – 99)
40219
Firmware month of 2nd terminal (1-12, 0 = DNE)
40220
Firmware day of 2nd terminal (1-31, 0 = DNE)
40221
Firmware year of 2nd terminal (00 – 99)
40222
Time left until a MultiStart Restart attempt (seconds). 0 if not counting down
40223
Ch 01 – 16 bitmap of armed (1) / not armed (0) status
40224
Ch 17 – 32 bitmap of armed (1) / not armed (0) status
40225
Ch 33 – 48 bitmap of armed (1) / not armed (0) status
40226
Ch 49 – 60, S01, S02 bitmap of armed (1) / not armed (0) status
40227
Counter used to track Modbus/Keypad writes to DE. (See Note 1 below)
40228
Counter used to track ASCII writes to DE. (See Note 1 below)
40230
Linear/Ramp Control Var Low (Writable)
40231
Linear/Ramp Control Var Hi (Writable)
40232
Linear/Ramp Control output limit low (4 – 20 mA mapped to 0-4095, Writable)
40233
Linear/Ramp Control output limit high (4 – 20 mA mapped to 0-4095, Writable)
40250
Speed on S01; range from 0-9999 RPM
40251
Speed on S02; range from 0-9999 RPM
40255
Analog output on A01 (%)
40256
Analog output on A02 (%)
40257
Analog output on A03 (%)
