ADDRESS DESCRIPTION
40247
Reset Service meter #9
40248
Reset Service meter #10
40249
Reset Service meter #11
Reading these registers will display zero. Writing any value to these registers will reset the (hours remaining) to the values
which had been previously setup for the (reset values).
25.0 KEY PRESS TABLE
KP FUNCTION
00 None (returns current display)
01 Cancel Timers
02 Test
03 Reset
04 Stop
05 View
06 Next
07 Up/Units
08 View Chan
09 F1
10 Right / Tens
11 Enter
12 Left/ Tens
13 F2
14 Menu
15 Down/Units
16 Esc
26.0 NOTES
26.1 Note 1: Modbus/Keypad and ASCII Write Counters
Register 40227 (Modbus/Keypad Write Counter) will increment when:
1. A Modbus function code 6 (preset single register) occurs.
2. A value is modified through the keypad (Applicable to DE-3000
Enhanced only).
Register 40228 (ASCII Write Counter) will increment when:
1. A “>(XXXP” command occurs, writing to the display board.
2. A “>(0XT” command occurs, writing to a terminal board.
These registers cannot be written to, and cycling power to the unit will not affect
the values.
26.2 Note 2: Auto/Manual Control of Analog Outputs
The auto/manual and increase/decrease current (in manual mode) for the cor-
responding analog output may be directly controlled by this register.
If the MSB=1, then the unit is in auto mode. Use the value of 8000h to put the
output loop into auto mode. If the MSB=0, then the unit will be in manual mode
and the lower 12 bits (range from 0-4095) will represent the 4-20mA output
(0=4mA and 4095=20mA)
