26.6 Note 6: Hour/Service Meter Labels
Each label is comprised of twenty ASCII characters, denoted as bytes within a
register. They are read in increasing order from left to right, as such:
Description Register High Byte Low Byte
Hourmeter label
47938 ASCII char 1
47939 2 3
47940 4 5
47941 6 7
47942 8 9
47943 10 11
47944 12 13
47945 14 15
47946 16 17
47947 18 19
47948 ASCII char 20
Each meter uses the same format as above, starting with the low byte on the first
register and ending on the high byte of the eleventh register. The starting and
ending index for each meter label is:
Description Starting Register Ending Register
Hourmeter 47938 47948
Service Meter #1 47954 47964
Service Meter #2 47970 47980
Service Meter #3 47986 47996
Service Meter #4 48002 48012
Service Meter #5 48018 48028
Service Meter #6 48034 48044
Service Meter #7 48050 48060
Service Meter #8 48066 48076
Service Meter #9 48082 48092
Service Meter #10 48098 48108
Service Meter #11 48114 48124
