Altronix AL600ULX User Manual

- 2 - AL600ULX Series
Do not exceed total output rating of 6 amp per unit.
AL600ULX, AL600ULPD4/CB and AL600ULPD8/CB available in larger enclosure add X to model AL600ULXX,
AL600ULXPD4/CB and AL600ULXPD8/CB.
Specifications:
Overview:
The AL600ULX is a power supply that converts a 115VAC / 60Hz input, to a 12VDC or 24VDC regulating output
(see specifications below).
The AL600ULX is the base power supply unit for the UL Listed multi-output power supply/charger series:
AL600ULPD4, AL600ULPD4CB, AL600ULPD8, AL600ULPD8CB, AL600ULXPD16, AL600ULXPD16CB
(Refer to AL600ULX Series Power Supply Configuration Reference Chart below).
AL600ULX Series Power Supply Configuration Reference Chart:
Altronix
Model Number Accessory Power Distribution Module(s) Number of Output(s) Class 2 Rated Power Limited Outputs Fused Outputs PTC Outputs Output Rating (amp) per Output Agency Listings UL Listings and File Numbers
AL600ULX(R)
-------- 1 -------- -------- -------- 6
UL File # S4707
UL 1481
UL Listed Power
Supplies for
Fire Protective
Signaling Systems.
----------------------------------------
UL 294
UL Listed for Access
Control System Units.
----------------------------------------
“Signal Equipment”
Evaluated to
CSA Standard
C22.2
No.205-M1983
AL600ULPD4
PD4UL 4 -------- x -------- 3.5
AL600ULPD4CB
PD4ULCB 4 x -------- x 2.5
AL600ULPD8
PD8UL 8 -------- x -------- 3.5
AL600ULPD8CB
PD8ULCB 8 x -------- x 2.5
AL600ULXPD16
Two (2)
PD8UL
16 -------- x -------- 3.5
AL600ULXPD16CB
Two (2)
PD8ULCB
16 x -------- x 2.5
Input:
• Input115VAC/60Hz,3.0amp.
Output:
• 12VDCor24VDCselectableoutput(s).
• 6ampcontinuoussupplycurrentat12VDCor24VDC.
• Filteredandelectronicallyregulatedoutputs.
• Shortcircuitandthermaloverloadprotection.
Battery Backup:
• Built-inchargerforsealedleadacidorgeltypebatteries.
• Automaticswitchovertostand-bybatterywhen
AC fails.
• Maximumchargecurrent0.7amp.
Battery Backup (cont’d):
• Zerovoltagedropwhenswitchedoverto
battery backup.
Supervision:
• ACfailsupervision(form“C”contacts).
• Lowbatterysupervision(form“C”contacts).
• Batterypresencesupervision(form“C”contacts).
Additional Features:
• ACinput,DCoutputandBATtroubleLEDindicators.
•Powersupply,enclosure,camlockandbatteryleads.
• Allmodelsareavailableinredenclosure
(add an “R” suffix to the part # e.g. AL600ULPD8R).
Power Supply Output Specifications:
Output Switch Position
12VDC SW1 - CLOSED (Fig. 1b, pg. 4)
24VDC SW1 - OPEN (Fig. 1b, pg. 4)
California
State Fire
Marshal
NYC
Dept. of
Buildings
Factory
Mutual
Approved

Altronix AL600ULX Specifications

General

Brand	Altronix
Model	AL600ULX
Category	Power Supply
Language	English
