Amada ADF4 - Parts Drawing 2 - Cover Assembly

© 1999 Amada
27
30 3EA-76544-01 Manifold Assembly
31 4MA-76545-01 Manifold Weldment
32 8PP-18835-00 Diaphragm Valve, RCA 20T
34 8PP-21462-00 Connector Elbow, 1/4" OD x 1/8" NPT
35 8PP-21464-00 Tubing, Poly, 1/4" OD
Parts Drawing 3
Manifold Assembly
Manifold Assembly
includes manifold weldment, diaphragm valves, connector elbows, poly tubing, and plug
30
35
34
32
31
Solenoid Enclosure
See Parts Drawing 5
Typical Manifold Assembly
Ref. Part Description
No. No.
Replacement Parts List
Torit Express
Parts and Service Line
800-365-1331
