© 1999 Amada32
80 3EA-76596-01 Dust Bin Assembly
81 5PM-76601-01 Seal, Rubber Gasket
81 5PM-76601-02 Seal, Rubber Gasket
82 8PP-58367-01 Caster, 1 5/8" Diameter, Rubber
83 8PP-55159-02 Clamp, Body
Parts Drawing 8
Dust Bin
Dust Bin Assembly
80
82
83
81
Ref. Part Description
No. No.
Replacement Parts List
Torit Express
Parts and Service Line
800-365-1331
