3.4 Assembly of Standard Equipment
(See Figure 1)
Remove all crating and strapping from the unit.
Remove all miscellaneous parts such as bolts,
nuts, or loose components before lifting the unit
off of the truck. Check the parts received
against the packing slips. If there are parts
missing, the carrier and your local Amada
Representative should be notified immediately.
NOTE
NOTE
3.4.1 Delta P Control
• Connect the lifting sling to the four (4)
cabinet lifting lugs.
• Use clevice pins, not hooks, on the
lifting sling.
• Do not lean unit on legs.
A crane or forklift is recommended for
unloading, assembly, and installation of
the dust collector.
Each item to be attached to the collector is
accompanied by a drawing that shows the
attachment process. Refer to both the
drawing and this manual to install the unit.
CAUTION
CAUTION
• All electrical work must be performed
by a qualified electrician according to
all applicable national and local codes.
• Turn electrical power OFF during
installation.
• Do not apply in classified hazardous
atmospheres without an appropriately-
rated enclosure.
NOTE
• Do not mount controls in high-vibration
areas without shock mounts.
• Do not mount controls in corrosive
atmospheres without an appropriate
enclosure.
• Do not operate with enclosure open.
CAUTION
Static-Free Electronic Assembly
• Use proper grounding and handling
procedures to prevent permanent
damage to this device.
• Handle printed circuit board by the
edges only.
• Avoid touching the socketed E
2
PROM
pins.
NOTE
In grounded systems, connect neutral to
control box to terminal L2 of the solid-state
control timer.
