© 1999 Amada4
Figure 1
Typical Installation
Customer-Supplied
208V, 3 Ph
Power Supply and
Disconnect Switch
Regulator
Setting: 90 to 100-psi
Coalescing Filter
Customer-Supplied
Compressed Air
Locate as close to
collector as possible.
