IPB-5000B
6. Description of Display Screens
6-22
GOOD: Count-up is done if the judgment is GOOD in current-supplied
monitoring.
Judgment in Monitor
Counting Manner
GOOD
Count-up
CAUTION
No Count-up
NG
No Count-up
WORK: Count-up is not done if the judgment is NG in current-supplied
monitoring.
Judgment in Monitor
Counting Manner
GOOD
WELD Counter counts-up.
WORK Counter counts-up (increment of
+1) when WELD
Counter reached the
set value.
CAUTION
WELD Counter counts-up.
WORK Counter counts-up (increment of
+1) when WELD
Counter reached the
set value.
NG
WELD Counter does not count-up.
WELD Counter is reset to 0 (zero) when
NG is reset.
WORK Counter does not count-up.
Note: The period for retaining the memory of counted numbers is
approximately 10 days since the day when a power supply is turned
off at latest.
(f) PRESET (TOTAL/GOOD)
Input the preset value of TOTAL/GOOD Counter.
(g) PRESET (WORK)
Input the preset value of WORK Counter.
(h) PRESET (WELD)
Input the preset value of WELD Counter.
(i) RESET
Resets the count.
(j) D-CHK
Checks the operation of Displacement Sensor. The amount of
displacement is shown on the right side of this button.
(k) BACK
Displays
 STATUS (2/2) Screen of the previous page.
