3. Specifications and Accessories
3-1
3. Specifications and Accessories
(1) Specifications
Items
MH-1201A
-00
MH-1201A
-41
MH-1201A
-10
MH-1201A
-20
MH-1201A
-50
Electrode Force
300 to 1200
N (Approx. 30 to 120 kgf) (Continuously adjustable)
Forcing Method
Spring
Electrode
Provided None
Electrode Diameter
φ8
mm φ12 mm *1
Electrode Stroke
35
mm
Throat Depth
74
mm
―
74 mm
Electrode-Driving
Method
Air Cylinder
Solenoid Valve
Operating Voltage
(Power Consumption)
100 V AC
(0.9
W)
24
V DC
(0.5
W)
― *2
100
V AC
(0.9
W)
Welding Current
10000
A (at 2% Duty Cycle) *3
Load Cell
Not mountable Mounted Not mountable
Frame
Provided None Provided
Mass
30
kg 11 kg 30 kg
Air Supply Pressure
0.5 to 0.7
MPa (Fluid: Air)
(2) Accessories
Check that all of the following accessories are provided.
Accessory
Name
Specification
MH-1201A
-00
MH-1201A
-41
MH-1201A
-10
MH-1201A
-20
MH-1201A
-50
Electrode
φ8
mm 2 pcs 1 pc None *1
Hexagon
Socket Head
Bolt
M8 x 35 4 pcs None 4 pcs
Plain
Washer
For M8 8 pcs None 8 pcs
Spring
Washer
For M8 4 pcs None 4 pcs
T-Nut ST
TST8 (Imao
Corp.-made)
4 pcs None 4 pcs
Hexagon
Socket
Screw Key
For M8
(Nominal size
6)
1 pc
Single
Open-Ended
Spanner
Nominal size
6
1 pc None
Operation
Manual
―
1 copy
Digital
Indicator
NTS-4231 None 1 pc None
