General Information
This manual provides complete instructions and sug-
gestions for handling, installing and servicing Amana
double gas wall ovens.
The directions, information and warnings in this
manual are developed from experience with, and care-
ful testing, of the product. If the unit is installed accord-
ing to the manual, it will operate properly and will re-
quire minimal servicing. A unit in proper operating or-
der ensures the customer all the benefits provided by
clean, modern gas cooking.
This manual contains all the information needed by au-
thorized Amana service technicians to install and ser-
vice Amana double gas wall ovens. There may be,
however, some parts which need further explanation.
Amana maintains a toll-free technical support line to
answer questions from authorized service technicians.
The number is 1-800-AMANA99.
Model Identification and
Ordering Replacement Parts
A unit’s model and manufacturing numbers are recorded
on its rating label. The rating label is located on the
upper door frame. It can be seen by opening the upper
oven door. Before ordering parts, write down the correct
model and manufacturing numbers from the rating label.
This avoids incorrect shipments and delays. Please refer
to the parts catalog when ordering replacement parts.
Amana Cooking Products Nomenclature
AO27DG1/W1
Amana
Color
Product Group
G - Gas Range
R - Electric Range
K - Cooktop
CO - Convection Wall
Oven
O - Wall Oven
DG1 -Downdraft
Gas Cooktop,
1 pc Grate
DH - Downdraft
Electric
Cooktop, Op-
tional
Halogen Car-
tridge
DS - Gas or Elec-
tric Downdraft
Slide-In
Range
G - Gas on Glass
Cooktop,
Sealed Burn-
ers
H - Halogen
Smoothtop
Range, 1 Dual
Element
2H - Halogen
Smoothtop
Cooktop, 2
Halogen Ele-
ments,1 Dual
R - Electric
Roughtop
Range, Calrod
Elements
S - Gas Range,
Sealed Burn-
ers
T - Radiant
Smoothtop
Range
2T - Radiant
Smoothtop
Range or
Cooktop, 1
Dual Element
Product Type
Features
Range Features - Variable
Cooktop Width
• 30 = 30"
• 35 = 35"
• 300 = 30", reduced
depth (20-1/4")
Wall Oven Width/Fuel
• 24SE2 = 24" Single
Electric (2.9 cu. ft.
oven), Soft Look Trim
• 27SE = 27" Single Elec-
tric (3.3 cu. ft. oven)
• 27DG = 27" Double Gas
(Two 3.3 cu. ft. ovens)
No Designator - Ebony
K - Chrome Top
L - Almond
LG - Almond, Glass
Door
W(1*) - White
WW - White on White
E(1*) - Ebony
* Enhancements: Elec-
tric Variable Intensity
System, Gas One Piece
Grates
Modern Main Cooking Products Nomenclature
PHO303UK
Color
D - Dishwasher
F - Electric Product
G - Refrigerator
K - Cooktop
M - Microwave Oven
P - Gas Product
X - Kit or Accessory
Product Group
Product Type
BR - Backguard Kit
DC - Electric
Single/
Double Con
vection Wall
Oven, Self-
Clean
DO - Electric Com
bination
Wall Oven,
Self- Clean
DU - Electric Slide-
In Range,
Self-Clean
ET - Electric
Cooktop (Coil
or
Downdraft)
GO - Gas Wall Oven,
Manual Clean
GT - Gas Cooktop
HO - Double Gas
Wall Oven,
Self- Clean
HU - Gas Slide-In
Range, Self-
Clean
KO - Gas Wall Oven,
Continuous
Clean
Series
Variable
Features
Variable
W - White
WW - White on White
WW1 - White on White/1
pc. grate
B - Black
B1 - Black/1pc grate
L - Almond
K - Chrome Top
D - Black Glass
Fuel
N - Natural Gas
Only
U - Universal (Set
for natural gas)
1 - 120 Volts,
60 Hz.
2 - 240 Volts,
60 Hz.
