Amana ASPT61D14 Series User Manual

6
Blower
Access
Panel
Secondary
Drain Port for
Upflow/Downflow Application
Secondary
Drain Port
for
Horizontal
Application
Tu bi ng
Panel
EXTERNAL PART TERMINOLOGY
Figure 7
INTERNAL PART TERMINOLOGY
Figure 6
ACCESS PANEL CONFIGURATION FOR DOWNFLOW
OR HORIZONTAL RIGHT
Figure 9
Coil Slides
on the downflow bracket
IMPORTANT NOTE:
Ensure coil slides on the rails along the groove provided on the drain pan side
walls. Failure to do so will result in improper condensate drainage.
COIL INSTALLATION FOR DOWNFLOW
Figure 8

Amana ASPT61D14 Series Specifications

General

Brand	Amana
Model	ASPT61D14 Series
Category	Air Handlers
Language	English
