TROUBLESHOOTING
EE
No display (EE
display is EMG
mode)
INTERNAL FAULT
• No power supply to ID blower / no
24 volt power to PCB
• Blown fuse or circuit breaker
• PCB has an internal fault
• Manual disconnect switch OFF • No power supply to ID blower / no 24 volt power to PCB • Blown fuse or faulty circuit breaker • Control board has internal fault
Eb E_Eb No Display
Selecting "no heater kit" and
receiving electric heat demand
• No heater kit selected
Ed E_Ed
Check Heater Kit Dip
Switches
(CHECK HTR DIPSW)
Heater Kit dip switches not set
properly
• Invalid heater kit selected
E5 E_E5 BLOWN FUSE Fuse Open
• Fuse (F1U) is blown • Connector TB10 is open
EF E_EF
Auxiliary Contacts Open
(AUX ALARM FAULT)
Auxiliary Switch Open
• High water level in the evaporation coil • The connected alarm device is activated • Auxiliary Alarm terminals (TB4, TB5) are open
d0 E_d0
Data Not Yet On Network
(NO NET DATA)
Data not on Network • No shared data on the network
d1 E_d1
Invalid Data On Network
(INVALID DATA)
Invalid Data on Network • Wrong shared data on the network
d4 E_d4
Invalid Memory Card data
(INVALID MC DATA)
Invalid Memory Card Data • Wrong memory card data
b0 E_b0
Blower Motor Not Running
(MOTOR NOT RUN)
Blower Motor not running
• Fan/motor obstruction • Power interruption (low voltage) • Incorrect / loose wiring
b1 E_b1
Blower Communication Error
(MOTOR COMM)
Blower Motor Communication error
• Incorrect / loose wiring • Power interruption (low voltage)
b2 E_b2
Blower Motor HP Mismatch
(MOTOR MISMATCH)
Blower Motor HP Mismatch
• Incorrect size motor • Invalid shared data
b3 E_b3 No Display
Blower Motor operating in Power,
Temp or Speed Limiting conditions
• Fan/motor obstruction or blocked filters • Power interruption (low voltage) • Incorrect wiring • Blockage in the airflow (ductwork) or ductwork undersized
Error
Code
De scri p tion P ossi b l e Ca use sClimateTalk MessagePCB LED Display
• Assure 208/230 volt and 24 volt power to blower and control board. • Check fuse F2U on control board • Check for possible short in 208/230 volt and 24 volt circuits. Repair as necessary. • Replace the control board. • Select the valid heater kit on thermostat • Valid dip switch selection (heater kit selection out of range of the unit configuration) • Set correct dip switches • Replace fuse • Check wiring to AUX alarm, heater kit, communication connection. • Replace the control board After recovering the system, E5 will still be displayed on the indoor PCB (about 30 seconds). BLOWN FUSE will still be displayed on the thermostat within 45 seconds. They will be cleared automatically. • Check water level in drain pan • Check alarm device. • Close Auxiliary terminals TB4 and TB5 if not used After recovering the system, EF will still be displayed on the indoor PCB (about 30 seconds). AUXILIARY CONTACTS OPEN will still be displayed on the thermostat within 45 seconds. They will be cleared automatically. • Populate shared data set using memory card. • Populate shared data set using memory card. • Replace circuit board • Rewrite data using the correct memory card • Check for obstruction on the fan/motor • Verify the input voltage at the motor • Check wiring or tighten wiring connections if needed • Replace circuit board or motor • Check wiring or tighten wiring connections if needed • Verify the input voltage at the motor • Replace circuit board or motor • Correct motor installation • Populate shared data set using memory card. • Check for obstruction on the fan/motor/ductwork, clean filters • Verify the input voltage at the motor • Check wiring • Replace motor
Corrective Actions
