Amana AVZC18 Series User Manual

5
ACCESSORIES
AVPEC
For heater kit installation, it is important to set the capacity of the electric heater at Set-up menu on thermostat and DIP switch on
indoor unit control board. For more information, please see indoor unit I/O manual.
*Revision level that may or may not be designated.
NOTE: Airflow selection should meet the minimum requirements as mentioned in the air handler installation instructions.
+
For match up with a 2 ton outdoor unit: Heater kit application shall not exceed 10 kW.
++
For match up with a 3 ton outdoor unit: Heater kit application shall not exceed 15 kW.
ACCESSORIES
MODELS
HKSX03XC HKSX05XC HKSX06XC HKSX08XC HKSX10XC
HKSC05XC HKSC08XC HKSC10XC
HKSC15XA HKSC15XB
HKSC15XF
HKSC19CA
HKSC19CB
HKSC20DA
HKSC20DB
HKSC20XF
HKSC25DC
AVPEC25B14A* XXXXXXXX
AVPEC37C14A* XXXXXXXXXXXX
AVPEC59D14A* XXXXXXXXXX XXX
AVPEC61D14A* XXXXXXXXXX XXXX
NOTE: For emergency mode heating, set the dipswitch on PCB. For heating mode, use the thermostat user menu.
Heater Kit
Selection AVPEC25B14A* AVPEC37C14A* + AVPEC59D14A* ++ AVPEC61D14A* S-9 S-10 S-11 S-12
No hea ter - - - - OFF OFF OFF OFF
First 3 5 5 5 ONONONON
Second 5 6 6 6 ON ON ON OFF
Third 6 8 8 8 ON ON OFF ON
Fourth 8 10 10 10 ON ON OFF OFF
Fifth 10 15 15 15 ON OFF ON ON
Si xth X 19 20 20 ON OFF ON OFF
Seventh X X X 25 ON OFF OFF ON
VALID SWITCH SETTINGS
Heater kW Dip Switch Setting Indoor PCB DS Bank 3
