Amana AVZC18 Series User Manual

61
SERVICING
b4 E_b4
Blower Trip or Lost
Rotor (MOTOR TRIPS)
Blower Motor - Current Trip (or) Lost
Rotor
• Fan/motor obstruction or abnormal motor loading • Power interruption (low voltage) • High loading conditions, blocked filters • Blockage in the airflow (ductwork) or ductwork undersized
• Check for obstruction on the fan/motor/ductwork • Verify the input voltage at the motor • Check filters, grills, duct system, coil air inlet/outlet for blockages. • Replace motor
b6 E_b6
Voltage or Temperature
Trip (MOTOR VOLTS)
• Blower motor stops for over/under
voltage
• Bower motor stops due to PCB
over heating
• High AC line voltage to ID blower • Low AC line voltage to ID blower • High ambient temperatures • Fan/motor obstruction or blockage in the airflow
• Verify line voltage to blower is within the range specified on the ID blower rating plate • See "Installation Instructions" for installation requirements • Check power to air handler blower • Check for obstruction on the fan/motor/ductwork • Check wiring • Replace motor
b7 E_b7
Incomplete Parameters
Send to Motor
(MOTOR PARAMS)
ID blower motor does not have
required parameters to function.
Motor fails to start 40 consecutive
times.
• Wrong / no shared data on the network • Locked motor rotor condition
• Check for locked rotor condition (see above error code for details) • Replace circuit board or motor
b9 E_b9 No Display
Low Indoor Airflow (without Electric
Heat mode)
• Fan/motor obstruction or blocked filters • Restrictive ductwork or ductwork undersized •
ID motor failure
• Check for obstruction on the fan/motor • Check ductwork/filter for blockage, clean filters • Remove obstruction. Verify all registers are fully open • Check the connections and the rotation of the motor • Verify the input voltage at the motor • Verify ductwork is appropriately sized for system. Resize/replace ductwork if needed • Replace motor
9b E_9b LOW ID AIR EH MODE
Low Indoor Airflow (with Electric
Heat mode)
• Fan/motor obstruction or blocked filters • Restrictive ductwork or ductwork undersized • ID motor failure • Combination mistake of outdoor unit and indoor unit
• Check for obstruction on the fan/motor • Check ductwork/filter for blockage, clean filters • Remove obstruction. Verify all registers are fully open • Check the connections and the rotation of the motor • Verify the input voltage at the motor • Verify ductwork is appropriately sized for system. Resize/replace ductwork if needed • Replace motor
70 E_70 EEV OPEN CKT EEV disconnection detected
• Indoor EEV coil not connected • Incorrect wiring to EEV
• Check Indoor EEV coil connection (PCB and junction connector) • Replace EEV coil • Check the resistance value of EEV coil (refer service manual) • Replace the control board
73 E_73 LIQ TEMP FLT Liquid side thermistor abnormality
• Open (or) short circuit of the liquid thermistor (X5A) • Liquid thermistor reading incorrect or values outside the normal range
• Check the connection to liquid thermistor (PCB and junction connector) • Check the resistance value of the thermistor (refer service manual) • Replace thermistor • Replace the control board
74 E_74 GAS TEMP FLT Gas side thermistor abnormality
•
Open (or) short circuit of the gas thermistor (X5A)
• Gas thermistor reading incorrect or values outside the normal range
• Check the connection to gas thermistor (PCB and junction connector) • Check the resistance value of the thermistor (refer service manual) • Replace thermistor • Replace the control board
75 E_75 PRESSURE FLT Pressure sensor abnormality
• Open (or) short circuit of the Pressure sensor (X15A) • Pressure sensor reading incorrect or values outside the normal range
• Check the connection to pressure sensor (PCB and junction connector) • Check the output voltage of the pressure sensor (refer service manual) • Replace pressure sensor • Replace the control board
77 E_77 No Display
Indoor Unit - Thermostat
communication error (start-up &
during operation)
• Incorrect wiring between ID unit and thermostat • Thermostat failure • Power interruption (low voltage)
• Check for thermostat and indoor unit wiring • Verify the input voltage at the ID unit and thermostat • Replace control board or thermostat • Press "LEARN" button on PCB for more than 5 seconds to reestablish network
Corrective Actions
Error
Code
Description Possible CausesClimateTalk MessagePCB LED Display
INDOOR UNIT ERROR CODES
