PRODUCT IDENTIFICATION
ACCESSORIES
15 Rev. 2
From furnace Flow To Chimney
YES
YES
NO
NO
Vent Damper
Install vent damper
with actuator to
sides of vent only.
Do not mount vent
damper with
actuator above
or below the vent.
From furnace
Flow
To Chimney
Vent
Damper
Install vent damper
with actuator in
any position.
Vertical Vent InstallationHorizontal Vent Installation
COMMMON VENT KIT
Kit Model
Numbers
Vent Diameter
Inches
CVK 4 4
CVK 5 5
CVK 6 6
CVK 7 7
CVK4-7
COMMON VENT KITS
GUIA GCIA
GUIB GCIB
GUIC GCIC
GUID
Used on Models
CVK4-7
COMMON VENT KITS
DEHUMIDISTAT
Model Number
2273W-21
Setpoint - Humidity Range 30% to 80% RH
Operating Ambient 10° to 40° C (50° to 104° F)
Differential 5%
Volts 120
Amps 1
HZ 60
DEHUM1
DEHUMIDISTAT SPECIFICATIONS
GUIV
DEHUM1
DEHUMIDISTAT
Used on Models
