FURNACE SPECIFICATIONS
1. These furnaces are manufactured for natural gas operation. Optional LP Conversion Kits are available to convert to
propane gas.
2. For elevations above 2000 ft. the rating should be reduced by 4% for each 1000 ft. above sea level. The furnace must not
be derated, orifice changes should only be made if necessary for altitude.
3. The total heat loss from the structure as expressed in TOTAL BTU/HR must be calculated by the manufactures method
of in accordance with the "A.S.H.R.A.E. GUIDE" or "MANUAL J-LOAD CALCULATIONS" published by the AIR CON-
DITIONING CONTRACTORS OF AMERICA. The total heat loss calculated should be equal to or less than the heating
capacity. Output based on D.O.E. test procedures, steady state efficiency times output.
4. Minimum Circuit Ampacity calculated as: (1.25 x Circulator Blower Amps) + I.D. Blower Amps.
18 Rev. 2
* Off Heating - This fan delay timing is adjustable (60, 90, 120, 180 seconds). 90 seconds as shipped.
MODEL
GUIB045A30
GUIB045B30
GUIB045CX30
GUIB070A30
GUIB070B30
GUIB070CX30
GUIB070A40
GUIB070B40
GUIB070CX40
GUIB090A30
GUIB090B30
GUIB090CX30
GUIB090A50
GUIB090B50
GUIB090CX50
GUIB115A40
GUIB115B40
GUIB115CX40
GUIB115A50
GUIB115B50
GUIB115CX50
GUIB140A50
GUIB140B50
GUIB140CX50
Btuh Input (US) 46,000 69,000 69,000 92,000 92,000 115,000 115,000 140,000
Output (US) 36,800 55,200 55,200 73,600 73,600 92,000 92,000 110,400
A.F.U.E. 80% 80% 80% 80% 80% 80% 80% 80%
Rated External Static (WC) .10 - .50 .12 - .50 .12 - .50 .15 - .50 .15 - .50 .20 - .50 .20 - .50 .20 - .50
Temperature Rise °F 35 - 65 35 - 65 35 - 65 40 - 70 40 - 70 40 - 70 35 - 65 45 - 75
Pressure Switch Trip Point -1.80 -1.42 -1.42 -1.30 -1.30 -1.10 -1.10 -1.20
Blower Wheel (D x W)" 9 x 8 9 x 8 10 x 6 10 x 8 10 x 8 10 x 7 10 x 9 10 x 9
Blower Horsepower 1/3 1/3 1/2 1/2 1/2 1/2 3/4 3/4
Blower Speeds 4 4 4 44444
Max CFM @ 0.5 E.S.P. 1200 1290 1450 1380 1975 1590 1985 2050
Power Supply 115-60-1 115-60-1 115-60-1 115-60-1 115-60-1 115-60-1 115-60-1 115-60-1
Min. Circuit Ampacity (MCA) 9.5 10.1 11.5 8.6 15.3 13.5 13.8 14.8
Max. Overcurrent Device 15 15 15 15 20 15 15 15
Transformer (VA) 40 40 40 40 40 40 40 40
Heat Anticipator 0.7 0.7 0.7 0.7 0.7 0.7 0.7 0.7
Limit Setting °F 250 200 210 180 190 160 180 160
Aux. Limit °F. 160 160 160 160 160 160 160 160
Fan Delay On 30 secs. 30 secs. 30 secs. 30 secs. 30 secs. 30 secs. 30 secs. 30 secs.
Off Heating * 90 secs. 90 secs. 90 secs. 90 secs. 90 secs. 90 secs. 90 secs. 90 secs.
Off Cooling 45 secs. 45 secs. 45 secs. 45 secs. 45 secs. 45 secs. 45 secs. 45 secs.
Gas Supply Pressure (Nat/LP) 7" / 11" 7" / 11" 7" / 11" 7" / 11" 7" / 11" 7" / 11" 7" / 11" 7" / 11"
Manifold Pressure (Nat/LP) 3.5 " / 10" 3.5 " / 10" 3.5 " / 10" 3.5 " / 10" 3.5 " / 10" 3.5 " / 10" 3.5 " / 10" 3.5 " / 10"
Orifice Size (Nat/LP) #43 / #55 #43 / #55 #43 / #55 #43 / #55 #43 / #55 #43 / #55 #43 / #55 #43 / #55
Number of Burners 23344556
Vent Connector Diameter 4" 4" 4" 4" 4" 4" 4" 4"
Shipping Weight (lbs.) 140 151 152 169 178 190 194 198
