FURNACE SPECIFICATIONS
5
*MEC96
„ Natural Gas BTU/h
†
‡
Vent pipe must be either 2" or 3" in diameter, depending upon furnace input, number of elbows, length of run
and must be 2" or 3" diameter PVC.
Minimum Circuit Ampacity = (1.25 x Circulator Blower Amps) + ID Blower amps. Wire size should be determined
May use fuses or HACR-type circuit breakers of the same size as noted.
Notes
 All furnaces are manufactured for use on 115 VAC, 60 Hz, single-phase electrical supply.

" FPT


and noise issues.

greater clearances than the minimum clearances listed above. In all cases, accessibility clearance must take precedence
over clearances from the enclosure where accessibilit
y
clearances are
g
reater.
*MEC96
0302BNA
*MEC96
0402BNA
*MEC96
0603BNA
*MEC96
0803BNA
*MEC96
1004CNA
*MEC96
1205DNA
Heating Data
Hi gh Fire Input¹ 30,000 40,000 60,000 80,000 100,000 120,000
Hi gh Fire Output¹ 28,800 38,400 57,600 76,800 96,000 115,200
Low-Fire Stea dy-State Input¹ 21,000 28,000 42,000 56,000 70,000 84,000
Low-Fire Steady-Sta te Output¹ 20,160 26,880 40,320 53,760 67,200 80,640
AFUE² 969696969696
Temperature Ris e Ra nge (°F) - 20 - 50 20 - 50 35 - 65 35 - 65 35 - 65
Vent Di a meter³ 2" - 3" 2" - 3" 2" - 3" 2" - 3" 2" - 3" 2" - 3"
No. of Burners 223456
Circulator Blower
Available AC @ 0.5” ESP 1.5 - 2 1.5 - 3 1.5 - 3 1.5 - 3 1.5 - 4 3 - 5
Si ze (D x W) 10" x 8" 10" x 8" 11" x 8" 11" x 8" 11" x 10" 11" x 11"
Horsepower @ 1075 RPM 1/2 1/2 1/2 1/2 1 1
Speed 555555
Filter Size (in²)
Permanent 487 487 731 683 853 1024
Di s pos able 244 244 365 341 427 512
Electrical Data
Min. Circuit Ampacity
4
8 8 8 8 13.3 13.3
Max. Overcurrent De vi ce (a mps )
5
15 15 15 15 15 15
Shipping Weight (lbs)
N/AN/AN/AN/AN/AN/A
